HH Tessen Array TNA-2120SA Act ...

£1,299.00 Available to Order

HH Tessen Array TNA-2120SA Active 3-channel Subwoofer

£1,299.00

Available to Order

Place your order today and we will email you when we have an estimated delivery date.

Includes Christmas Exchange & 3-Year Warranty

We're the first and only UK guitar retailer to offer a 3-year warranty & extended Christmas Exchange as standard.
Buy now and exchange until 31st January 2025

Notify me when in stock

We'll share some similar product recommendations, and if the item does not come back in stock we will let you know.

Frequently Bought Together


Total Price: £

Manufacturer's ID: TNA-2120SA:U

The TNA-2120SA is a multi-channel active subwoofer for powering a complete TNA line array system. The TNA-2120SA features two high power 12-inch low frequency woofers with exceptionally high output. The TNA-2120SA active subwoofer houses three channels of high performance amplification and cutting edge built in DSP presets. As a modular system, the TNA-2120SA is capable of powering up to 6 x TNA-2051 line array satellite cabinets. With Integrated rigging hardware, and optional suspension bracket and dolly board, the TNA-2120SA can be installed quickly and easily. The TNA-2120SA offers a max SPL of 137dB and offers a frequency response as low as 35Hz. When combined upto six TNA-2051's, the TNA-2120SA offers an ideal venue installation or point source solution without the extra expense of rack amplifiers and processors. Ideal for venues, schools, sports, gyms, hotels and more.

Specification

System Type 2 x12-inch Active Subwoofer, Bass Reflex, with Three channel internal amplifier (Two HF Amplifier Channels for external satellites)
Frequency Response (-3) 52Hz - 150Hz * Tuned with internal DSP Presets
Max SPL 134dB continuous, 137dB Peak
Inputs Balanced XLR Connector
Indicators Power, Mute/Protect, Clip Indicator, Preset Mode
Protection Comprehensive protection and clip free limiting + clip indicator
Input Impedance (Bal/Unbal) 22K Balanced, 10K unbalanced
Grille 1.5mm Thickness, Hexagonal mesh
Finish Painted Black
Mounting Bracket TNA-BRK1
Unit Weight 36.7Kg, 80.9 lbs
Frequency Response (-10) 52Hz - 200Hz
LF Driver 2 x 12-inch HH designed high performance driver
Power System Amplifier Power Rating: 4800W Peak, 2400W Continuous, 1200W RMS
Subwoofer Amplifier Power Rating: 2400W Peak, 1200W Continuous, 600W RMS
Satellite Amplifier Power Rating: Two Channels of 1200W Peak, 600W Continuous, 300W RMS
Outputs 1 x Balanced XLR Link Out, 1 x Balanced XLR Sub out with 2 way/3 way mode switch and Ground Lift Switch. 2 x locking speakon connectors for external TNA-2051 cabinets
DSP 56bit DSP controlling Crossover, EQ, phase and time optimisation for array cabinets. Six built in DSP presets for typical use cases
Controls Master Volume, DPS Preset Switch
Cabinet 15mm Plywood
Mounting Points 8 x M8 fixings for included metal side brackets, and optional TNA-BRK1 flying bracket assembly
Unit Dimensions (H x W x D) 730 x 475 x 460mm, 28.7" x 18.7" x 18.1"
