Manufacturer's ID: JD-M82
The Bass Envelope Filter delivers classic, analog, envelope filter sounds in an easy-to-use and compact pedal designed specifically for bass. Separate Dry and Effect controls let you dial in the perfect mix of effected and direct signals, so you can bring the funk without losing the low end. It’s wide range of filter tones can be shaped with the Decay and Q controls, and a simple twist of the Sensitivity knob can tailor the pedal for your attack—as well as adjust for passive or active basses.
Specification
- Input Impedance: 1 MΩ
- Output Impedance: 100 Ω
- Max Input Level*: -15 dBV
- Max Output Level: +8 dBV
- Noise Floor*: -94 dBV
- Filter Sweep (fc): 76 Hz to 3.2 kHz
- Sensitivity Range: 46 dB
- Max Sensitivity at 500 Hz
- fc = 3.2 kHz -23 dBV
- fc = 100 kHz -39 dBV
- Decay Stop Freq.: 76 Hz to 1.3 kHz
- Filter Gain at fc
- Q Min, fc = 76 Hz +8 dB
- Q Max, fc = 76 Hz +18 dB
- Q Min, fc = 3.2 kHz +8 dB
- Q Max, fc = 3.2 kHz +26 dB
- Bypass: True Hardwire
- Current Draw: 6 mA
- Power: 9 volts DC
